3 Way Electric Actuated Control Valve

3 Way Electric Actuated Control Valve

3 way electric control valve has two action types: electric mixing(converging) control valve and electric diverting(diverging) control valve.The 3 way electric control valve is composed of PSL series and ***0 series linear electric actuator and *-way valve body.The electric actuator is an electronic integrated structure with a servo amplifier. The control signal (***0mADC or **5VDC) and the power supply can control the valve opening to achieve to control the parameters of pressure, flow, liquid level and temperature. The electric *-way mixing control valve is mainly used for mixing two fluids into a third fluid; the 3 way diverging electric control valve is mainly used for dividing one fluid into two fluids.



Body is carbon steel

1 Valve Body WCB LCB WC9

2 Valve Seat **4 **4 **4

3 Valve Plug **4 **4 **4

4 Guide Cage **4 **4 **4

5 Valve Bonnet WCB LCB WC9

6 Valve Stem **4 **4 **4

7 Packing PTFE/Flexible graphite

8 Spring *5Mn

9 Nut **4 **4 **4

Technical Parameter for BCST 3 Way  Electric Actuated Control Valve

Bonnet Type standard type(**7～***0℃),high temperature type(***0～***0℃),

cryogenic type(**0～***6℃),bellows type(**0～***0℃)

Seal Packing PTFE, flexible graphite

Plug Type double guide cage type plug

Flow characteristics linear,equal percentage

Actuator Type **1L electric actuator,PSL electric actuator,or other specified actuator

Actuator

Parameters voltage:**0V/*0Hz, signal:***0mA or **5V·DC,output signal:***0mA·DC

Protection level:IP*5,Explosion proof:ExdⅡBT4(ExdⅡBT6 customized),hand function: handle.

Ambient temperature:**5～**0℃;humidity:≤*5%.
