7'' LCD digital readou dro for milling lathe machines

Product Description

*-inch LCD digital readout(DRO)(WB****0) Using *-inch real color LCD screen, mechanical keys, large font display, after power failure to remember the current position wide voltage range, voltage AC *0V***0V, all can work normally. Optional RS**2 interface, convenient to communicate with computer or PLC, feedback data. LCD digital readout(DRO) can be installed on a variety of machine tools or equipment, such as lathes, milling machines, grinding machines, boring machines, spark machines, fine hole discharge machines.
with a grating scale for the machine tool to display measurement positioning. Features: Zero Cleaning
reset
mm / inch mode
**0 sets of coordinates
memory off;
Center of1 / 2
linear error compensation
sleep mode
pure **0 sets of Sdm datum;
ABS / INC mode
calculator
circle drilling
oblique line drilling
inclined plane processing
circular arc processing
lathe (matching)
rectangular light output
digital filtering
vibration filtration
radius / diameter Specifications: Voltage range: *0 VAC ~ **0 V / *0 Hz ~ *0 Hz Acceptable signal: TTL or RS**2 Connector: DB9 Acceptable Resolution: 0.1μm、0.2μm、0.5μm、1μm、2μm、5μm、*0μm Material: ABS Color: black LCD size: 7 inch TFT Axis numbers: 2 axis and 3 axis Power consumption: ＜*5W Operating temperature: 0℃~*5℃ Storage temperature: **0℃~*0℃ Operation keys: mechanical keys Item size: **0 * **5 * *5mm Item weight:2 axis: 1.*5KGS Package size: **0 * **0 * **0mm Package weight: 2.1KGS
