Description
Winner
motorized ball valve consists of on/off type or 3-point type
actuator and W8BV… series ball valve，which
have compact structure，stable
operation，excellent capacity of water stoppage,
large water flow rate, zero dirt block and low torque.
Winner motorized ball valves are widely used in HVAC system,
heating system, water treatment system and some industrial
equipments.
Application
HVAC
system.
heating
system.
Water treatment
system,.
Industrial
equipments
Technical
data
Valve
body:
Medium:
cold/hot water, with 50% glycol
Temperature of medium:
2°C...90°C
Rated pressure:
PN20
Pipe connector: internal
thread
Ambient temp.
range: -20…+70°C；0…95%RH Size:
1/2, 3/4 and 1 Valve type: 2-way and
3-way
Material
Valve body:
forged brass, Hpb59-1
Seal: ball: EPDM+PTFE,
with double O-ring
Ball:
nickle-plated brass
stem: EPDM
O-rings， with double
O-ring
Actuator shell:
PC+10GF
Actuator revolving shaft:
POM
Valve body
Specification
| Model No. | type | Inch | Kvs(m3/h) | △Pvmax(KPa) | △Ps(KPa) |
| W8BV215 | 2 way | 1/2 | 6.15 | 1000 | 1400 |
| W8BV220 | 2 way | 3/4 | 10.5 | 1000 | 1400 |
| W8BV225 | 2 way | 1 | 16.1 | 1000 | 1400 |
| W8BV315 | 3 way | 1/2 | 3.95 | 1000 | 1400 |
| W8BV320 | 3 way | 3/4 | 6.80 | 1000 | 1400 |
| W8BV325 | 3 way | 1 | 15.8 | 1000 | 1400 |
| Model No. | Working Voltage | type | torque | Consumption | On/off time | Valve body |
| WRA-6320 |
230VAC±15% 50/60Hz |
3-piont or on/off | >4N.m | 7W |
50Hz:16S 60Hz:12S |
W8BV215 W8BV220 W8BV225 W8BV315 W8BV320 W8BV325 |
| WRA-6320A | On/off | |||||
| WRA-6310 |
110VAC±15% 50/60Hz |
3-piont or on/off | ||||
| WRA-6310A | On/off | |||||
| WRA-6302 |
24VAC±15% 50/60Hz |
3-piont or on/off | ||||
| WRA-6302A | On/off |
Dimension:
Wiring diagram WRA-6320A,WRA-6310A,WRA-6302A  WRA-6320, WRA-6310,WRA-6302 Packing information Actuator Packaging Detail: 57 pcs/CTN. Carton: 51cm*33cm*31cm . G.W: about 23kg/CTN. 1/2", 3/4" , 2 way Valve Packaging Detail: 72 pcs/CTN. Carton: 29.5cm*24.5cm*25cm . 1/2" G.W: about 15kg/CTN. 3/4" G.W: about 22kg/CTN. 1" , 2 way Valve Packaging Detail: 36pcs/CTN. Carton: 29.5cm*24.5cm*25cm . 1" G.W: about 22kg/CTN. 1/2" , 3 way Valve Packaging Detail: 60pcs/CTN. Carton: 29.5cm*24.5cm*25cm . 1/2" G.W: about 19kg/CTN. 3/4",1", 3 way Valve Packaging Detail: 30 pcs/CTN. Carton: 29.5cm*24.5cm*25cm . 3/4" G.W: about 13kg/CTN. 1" G.W: about 19kg/CTN. |
