Application
DPP-140
Al/PVC Blister Packing Machine with advanced performance, simple
operation, high output is the latest improved equipment in our
company. Its the most ideal packing equipment for large and
medium-sized pharmaceutical plant, health care factory and food
industry.
Characteristics
1)
Adopts import frequency transformers to control switch for longer
service life.
2) The die is located with location pin preciously and easy to make
replacement.
3) Adjustable travel, pressed forming, registering-heating, upper
and lower heat-sealing.
4) Completed automatic forming, feeding, heat-sealing,
mark-pressing, batch number printing and punching.
5) Adopts manual wheel to adjust the working position of
forming, pressing and punching.
6) Made of stainless steel both inside and outside of the
equipment.
Technique
Parameter
| Model | DPP-140 |
| Punch frequency(times/min) | 10~35 |
| capacity(Edit/hr) | 4200 Edit |
| Max formed area and depth(mm) | 130×100×25（standard depth:15mm） |
| Travel range(mm) | 50~125（adjustable） |
| Standard edition(mm) | 80×57(adjustable) |
| Air pressure(Mpa) | 0.4-0.6 |
| Air flow | ≥0.2m3/min |
| Power | 380V 50Hz 3.8KW |
| Main power(kw) | 1.5 |
| PVC hard piece(mm) | 0.15~0.5×140 |
| PTP aluminum foil(mm) | 0.02~0.035×140 |
| Dialysis paper(mm) | 50~100g×140 |
| Mould cooling | Tap water or recycle water |
| Dimension(mm) | 2314×635×1403(L×W×H) |
| Net weight(kg) | 750 |
| Gross weight（kg） | 820 |
| Packing size（mm） | 2500×800×1780（L×W×H） |
| noisy | < 75 db |
