Automatic tablet sorting machine By Ruian Aligned Technology Co., Ltd.,

Product Specification

Max output capacity(t/h):800000 (6mm Tablet)
Dedust route (m):6
Max lift height(mm):1220
Power supply:1P 220/110V 50-60Hz
Outer dimension(mm):550 550(H:1350-1500)

Product Description

The title goes here.


        Usage: Model SZS230 Uphill Deduster also employed many new
        designs, to allow and to ensure a better and safer
        production, This Uphill Deduster is able to act as both
        elevating and dedusting machine, which made it a usual
        combination with other tablet-compressing machine and metal
        detection machine, and also made it extremely applicable in
        the field of pharmacy, chemical engineering, electronics,
        and food. easy operation

        Features: Its advantage includes a long dedusting path,
        automatic tablet polish on all sides, and high-quality
        dedusting without damage to the tablet itself. In addition,
        it can act as a delivery device for any shape of tablet
        that needs to be deducted. Best of all, it corresponds with
        the GMP standard. The machine body, cover adopts modular
        design, easy to adjust the export height, the quick
        assembling connection structure, make the machine more
        efficient disassembly, installation, also cleaning without
        the dead angle of entrance and exit. The machine can do a
        360-degree circumference adjustment, convenient production,
        save space outstanding production efficiency, can satisfy
        Dia. 3-35mm shape tablets in the large-scale production,
        the new driving device design, so as to make the machine
        run more smoothly, low noise.
          Specification

                    Model

                    SZS230

                    Max output capacity(t/h)

                    800000 (Ф6mm Tablet)

                    Dedust route (m)

                    6

                    Max lift height(mm)

                    1220

                    Max tablet Dia(mm)

                    Ф25

                    Power supply

                    1P 220/110V 50-60Hz

                    Outer dimension(mm)

                    550×550×(H:1350-1500)

                    Weight(kg)

                    70

                    Compressed air

                    0.1m3/min 0.05Mpa

                    Vacuum

                    2.7m3/min -001Mpa

Country:	China
Model No:	SZS230
FOB Price:	3600 ~ 4000 / Unit ( Negotiable ) (Negotiable) Get Latest Price
Place of Origin:	zhejiang,China
Price for Minimum Order:	3600 per Unit
Minimum Order Quantity:	1 Unit
Packaging Detail:	wooden box
Delivery Time:	45 DAYS
Supplying Ability:	30 Unit per Month
Payment Type:	T/T, L/C
Product Group :	Tablet production line

Automatic tablet sorting machine

Ruian Aligned Technology Co., Ltd.

Product Specification

Product Description

Related Products Ruian Aligned Technology Co., Ltd.

Send a direct inquiry to this supplier

To:

I want to know:

Model	SZS230
Max output capacity(t/h)	800000 (Ф6mm Tablet)
Dedust route (m)	6
Max lift height(mm)	1220
Max tablet Dia(mm)	Ф25
Power supply	1P 220/110V 50-60Hz
Outer dimension(mm)	550×550×(H:1350-1500)
Weight(kg)	70
Compressed air	0.1m3/min 0.05Mpa
Vacuum	2.7m3/min -001Mpa
