BISPLATE 80 By Jinan Iron and Steel Group Co., Ltd,

BISPLATE 80

FOB Price

Get Latest Price

( Negotiable )

10 Metric Ton Minimum Order

Country:

China

Model No:

FOB Price:

( Negotiable )(Negotiable) Get Latest Price

Place of Origin:

Price for Minimum Order:

Minimum Order Quantity:

10 Metric Ton

Packaging Detail:

Delivery Time:

Supplying Ability:

Payment Type:

T/T, L/C

Product Group :

BISPLATE

Product Specification

Standard: AISI
Thickness: 6-100
Brand Name: BISPLATE
Type: Steel Plate
Technique: Cold Rolled
Special Use : Wear Resistant Steel
Width: 1600-2485
Length: 6000-12000

Product Description

BISPALTE 80
BISPLATE 80-a low alloy.high strength plate with a yield stress approximately three times that of carbon steel and featuring low carbon ,excellent notch toughness and good weldability and formability.

Applications
Utilising the high strength properties of BISPLATE 80 allows reduction in section thickness without loss of structural integrity.The following lists some applications where the strength advantage has been realized:

Bridges
Transport equipment(low loaders)
Storage tanks
High-rise buildings(columns)
Excavator buckets
Mining equipment(dump truck trays/longwall roof supports)
Induced draft fans
Lifting equipment(mobile cranes/ container handing equipment)

Available Size

Thickness(mm)	Regular size(width mm x length mm)
6-8	1600-2000x6000/8000
8-20	1600-3100x6000/8000/12000
20-50	2000-3100x6000/8000/12000
50-80	2000-3100x6000/8000
80-100	2485x6000

(Please contact for more detail if the width and length are irregular)

Chemical Composition Mass Percentage%

Thickness(mm)		C	Si	Mn	P	S	Cr	Mo	B
6-16	Max	0.18	0.3	1.25	0.018	0.008	-	0.25	0.0025
16-60	Max	0.21	0.30	1.55	0.018	0.008	0.3	0.3	0.0025
60-100	Max	0.19	0.7	1.25	0.018	0.008	0.9	0.4	0.0025

Mechanical Properties

Property	Standard	Typical
0.2% Proof Stress	≧690Mpa	750Mpa
Tensile Strength	790-930Mpa	830Mpa
Elongation in 50mm G.L	≧18%	26%

(Properties are related to the thickness,data in the table refers to the typical size of 20mm)

Charpy Impact Performance

Charpy-V Impact (Longitudinal)
	Thickness(mm)	Sample(mm x mm)	Temperature	Energy J
Standard	All	10 x 10	-20℃	40 (Min)
Typical	20	10 x 10	-20℃	160
Typical	20	10 x 10	-40℃	100

Hardness test   Typical 255 HBW
Test standard   BISPLATE 80 is manufactured in accordance with AS/NZS 3597
              Grade 700.All testing is CNAS approved
Equivalent Specifications BISPLATE 80 is equivalent to
                       ASTM A514    JIS G3128
                       ISO 4950-3 Grade E690     EN10137-2 Grade S690Q
                       ISO9328-4 Grade P690TQ
Manufacturing Tolerance   In accordance with AS/NZS1365 or GB/T709-2006
Size tolerance   Tight tolerance may be available on negotiation
Surface finish   Shortblasted

Fabrication
BISPLATE is a high strength steel manufactured with a controlled carbon equivalent for optimum weldability. BISPLATE 80 can be successfully welded to itself and a range of other steels,provided low hydrogen consumables are used and attention is paid to preheat,interpass temperature,heat and the degree of joint restraint.Stress relieving can be achieved at 540 ℃-570℃. Heating above this temperature should be avioded to minimise any adverse effects on mechanical properties. Cold forming can be successfully conducted,provided due account is taken of the increased strength of the steel.
