Category 8 Ethernet Cable

Product Description

Per ANSI / TIA-568.2-D standard, it provides a new standard for the Category 8 network cabling solution and leads the copper twisted pair cabling into the next new era. Cat.8.1 regulation continues the RJ45 interface and is applied by shielded solution only, so far provide short-distance transmission by 30M in channel link and support 40G transmission. Cat 8 wiring scheme will be mainly used in the data center. So when building a new data center, it is recommended to use CAT.8 ethernet cable for structured cabling to meet higher bandwidth in the future.



Features

• GHMT CAT8 channel performance verified.
• Complied with the IEC61156-9 CAT8.2 cable requirement.
• IEEE802.3bt PoE type III 60W and IV 100W applications.
• 22AWG solid copper wire, Skin-Foam-Skin Polyethylene isolation OD 1.64mm.
• Aluminum foil around each pair, Tin plated copper braid for overall screen.
• CM, LSZH (IEC60332-1-2 / IEC 60332-3-24) and CM-LSZH dual rated jacket are available.
• OD 8.4mm.
•
•
• Applications

• Crxconec CAT.8 Lan cable could apply with different outlet such as keystone Jack and patch panel, faceplate and surface mount box, RJ45 Cat 8 STP RJ45 Connector is applicable with 24-26 AWG wire guage cable performed 2000MHZ(2GHZ )frequency, because of the highly specification, it usually used in the Data center or indoor working area.


  Cat.8 SSTP ethernet cable combined with keystone jack or toolless plug.



  Material & Structure

  Conductor: Bare Copper, 22AWG 0.63mm
  Insulation: Skin-Foam-Skin PE, OD 1.65mm
  Foil Screen: Aluminum / PET, T=50/12 μm
  Braid: Tinned Copper, 0.1mm x 6 x 16, Min. 45% Coverage
  Drain Wire: N/A
  Sheath: PVC CM or CMR, or LSZH, T=0.75mm, OD 8.4 ± 0.2mm

  GHMT Verified Cat.8 Copper System Certification

  CRXCONEC Cat.8 channel link are independently certified by reputed laboratories GHMT in Germany, based on 2 Connector channel under 30M and follow the standard of Class I ISO/IEC TR 11801-9901 Ed.1.0 (2014-08).



  Fluke Test Report

  CRXCONEC Cat.8 lan cable pass fluke test with ISO standard and TIA standard, we can pass both long length meters and short length meters.


  Cat.8 Channel Configuration

  Here below is CRXCONEC Cat.8 channel link demonstration, it is a channel link under 30M with high speed application.



  Packaging

  CRXCONEC Cat.8 lan cable has been packed by plastic wrap, and it is combined with 50m or 100 for one roll, it is according to the customer's request, each rope has its own box, and also you can pack your lan cable with wooden reel, it can let your cable much easier to manage.

  Purchase Information

  Price Term: FOB Taiwan or FOB Ningbo
  Payment Term: T/T, credit card, or pay pal
  Lead Time: 4 weeks after order confirmation
