Cement Mixer with Concrete Batching Plant

Product Description

If youre a high volume concrete products producer, you depend on your batch plant to set the pace. Only one batch plant measures up: HZS series from Zhengzhou Sinotech. HZS series is our top-of-the-line plant, capable of producing up to **0 yards per hour. Configure HZS series to your exact specifications, beginning with our legendary mixers. Behind every HZS series are more than *1 years of experience in batch plant design, manufacturing and construction. No matter what the production challenge, HZS series takes charge.

Custom design and construction separate HZS series from the rest. Zhengzhou Sinotech builds every HZS series from the ground up to meet our customers specifications. Choose from a complete range of performance-proven components, all from a single source:

Mixer designs and capacities

Plant control systems

Stack-up, low profile or below grade configurations

Custom bins and silos

Weigh belts or weigh batchers

Add augers, open or enclosed belt conveyors, holding hoppers, gantry buckets, monorail delivery systems and mixer washout systems. Zhengzhou Sinotech can assemble a total, unified system to provide you with smooth, dependable material flow throughout your entire plant.



Material Handling

Zhengzhou Sinotech offers a wide variety of material storage and handling components, in sizes and configurations to match your capacity needs and the layout of your plant. You can choose from cement or fly ash silos up to ***0 barrel/***0 cu. ft. capacity, aggregate bins to **0 tons and both open and enclosed conveyor systems.

Weighing system

All materials are weighed with weighing system for accuracy and ease of calibration. Load cells are matched and scaled to resist water and dust. Weighing accuracy of the aggregates is within +/*2% and cement/water to within +/*1% of the batch size. Our computerized control ensures that all materials are sequenced into the mixer at the appropriate time and in the correct amounts for your mix design every batch.

Automated Controls

Choose from an entire family of plant control systems. The HZS offers the highest level of batch plant automation and programmability. Run a high-volume batch plant from start to finish-batching, mixing, moisture control, even automated concrete delivery of different mix designs to multiple locations on demand. Its simple touch screen design means it is easy to learn and operate.

Aggregate Control System

Variables such as temperature and moisture content affect the quality of your finished product. The Aggregate Control System is an economical way to control those variables and improve performance. During wet weather it forces water from the material. In the winter months it acts to thaw/heat frozen material for use. A year-round solution, Aggregate Control System is easy to install in new or existing plants and can handle up to eight separate aggregate bins.

HZS Series,Stationary Concrete Batch Plant Model Number  HZS*5  HZS*5  HZS*0  HZS*0  HZS*5  HZS*0  HZS**0 Capacity (m³/h) *5 *5 *0 *0 *5 *0 **0 Mixer JS**0 JS**0 JS***0 JS***0 JS***0A JS***0B JS***0 Aggregate batcher PLD***0 PLD***0 PLD***0 PLD***0 PLD***0  PLD***0 PLD***0  Discharge height (m) 1.5~3.8 1.6~3.8 3.8 3.8 3.8 3.8 4 Material particle size （mm） *0 *0 *0 *0 *0 *0 *0 Cycle time (s) *2 *2 *0 *0 *0 *0 *0 Aggregate Weighing accuracy (0~***0KG)±2% (****0KG)±2% (0~***0KG)±2% (0~***0KG)±2% (0~***0KG)±2% (0~***0KG)±2% (0~***0KG)±2% Cement Weighing accuracy ±1% ±1% ±1% ±1% ±1% ±1% ±1% Water Weighing accuracy ±1% ±1% ±1% ±1% ±1% ±1% ±1% Additive Weighing accuracy ±2% ±2% ±2% ±2% ±2% ±2% ±2%

The advantages of HZS concrete batching plant:

1.HZS concrete mixing plant adopts the modular and fast assembling structure which is popular in the international market.

2.HZS concrete batching plant is collocated with compulsory concrete mixer with high performance. HZS concrete batching plant also have double computer control system.

3.HZS concrete mixing plant is featured by noise proof, anti dust pollution, environmental protection design. HZS concrete mixing plant is one new generation of concrete mixing equipment,

4.The central mixing of HZS concrete concrete mixing plant is conducive to the use of automation technique, which can enhance the productivity and save labor force and reduce cost.

5.HZS concrete batching plant can take microwave moisture measurement to accurately confirm the moisture content, which is able to guarantee the quality of concrete.

Country:	China
Model No:	HZS
FOB Price:	17000 ~ 200000 / Set (Negotiable) Get Latest Price
Place of Origin:	-
Price for Minimum Order:	17000 per Set
Minimum Order Quantity:	1 Set
Packaging Detail:	Standard Package
Delivery Time:	Sea Transportation
Supplying Ability:	99 Set per Year
Payment Type:	L/C, T/T
Product Group :	-
