Designed for
testing chain tension(manufacturing proof force testing or proof
load testing).
The chain proof load test applies a specific, heavy load to lifting
equipment (chains) using proof testing machines. This controlled
process verifies the chains safe load capacity and tensile strength
by ensuring it holds the weight without failure (e.g., excessive
elongation). Passing this industry-standard test confirms the
equipment is **0% safe for use, preventing accidents when handling
heavy loads.
Technical
parameters：(manufacturing proof force
testing)
|
Functions model |
Size range |
Peaking
holding （***0S adjustable） |
Testing
time （***0S adjustable） |
Data acquisition and printing | Auto stop when broken | Auto alert when chain blocked |
| CETT**0 | ￠***0mm | √ | √ | optional | √ | √ |
| CETT**6 | ￠****6mm | √ | √ | optional | √ | √ |
| CETT**0 | ￠****0mm | √ | √ | optional | √ | √ |
|
model parameters |
CETT**0 |
CETT**6 |
CETT**0 |
| Size range (mm) | ￠***0mm | ￠****6mm | ￠****0mm |
| Max single stroke length (M) | 6.0 | 6.0 | 6.0 |
| Control methods | PLC+RS**5+Frequency conversion servo program control | ||
| Max tension value (mm) | **0 | **0 | **0 |
| System max thrust (KN) | **0 | **0 | **0 |
| System working force(KN) | **0 | **0 | **0 |
| Motor power(KW) | 6.0 | 7.0 | *2.7 |
| Fastest speed of single stroke | *5S/6 M | *5S/6 M | *0S/6 M |
| Air pressure (Mpa) | ≥0.4 | ≥0.4 | ≥0.4 |
| Min setting number of links | >4 | >4 | >4 |
| PLC Failure alarm setting value | >*0% | >*0% | >*0% |
| Sampling voltage | DC*4V/***0mA | DC*4V/***0mA | DC*4V/***0mA |
| Dimension (LxWxH : M) | 8.5×1.0×1.8 | 8.5×1.1×1.8 | 9.6×1.1×1.*4 |
| Weight (T) | 1.5 | 2.5 | 3.5 |
