Full automatic Food Can wraparound packer

Automatic bottles infeed, automatic supplying the cardboard, automatic inspection, automatic wraparound.

    The bottles are transported by conveyor, and be inspected and arranged according to the programmed process, after finishing complete carton arrangement, the cardboard supplying mechanism will send the send the cardboard into the machine, and the bottle dropping mechanism will drop the bottles into the cardboard, and than the cardboard folding mechanism will fold the cardboard, glue it and seal it step by step. The formed the carton will be send out of the machine by the roller, which improves the production efficiency and realize full automatic manless production.

     Case packaging machine, wrap hinaround carton packaging machine, wrap around carton packing

Main configuration

l  PLC                                                                            Siemens

l  Frequency converter                                              Danfoss

l  Photoelectric sensor                                                 SICK

l  Servo motor                                                             Panasonic

l  Pneumatic components                                             SMC

l  Low-voltage apparatus                                           Schneider

l  Touch screen                                                    Schneider/Siemens



 Main equipment description

1. Conveyor system: the product will be divided and inspected on this conveyor.

2. Automatic cardboard supplying system: This equipment is installed in the side of the main machine, which stores the carton cardboards, the vacuumed sucking disk will indraft the cardboard into the guide slot, and then the belt will transport the cardboard into the main machine.

3. Automatic bottle dropping system: This system separates the bottles in carton unit automatically, and then drops the bottles automatically.

4. Cardboard folding mechanism: the servo driver of this mechanism will drive the chain to fold the cardboard step by step.

5. Lateral carton pressing mechanism: the lateral cardboard of carton be pressed by this mechanism to form the shape.

6. Top carton pressing mechanism: The cylinder presses the up cardboard of the carton after glueing. It is adjustable, so that it can suitable for different size of carton

7. Automatic system control cabinet:

Case wraparound machine adopt Siemens PLC to control the complete system of the machine.

The interface is Schneider touch screen with good display of production management and status.
