Fully Automatic Insulating Glass Panel Inflating Line 2840

Product Description

Equipment Features:

1. Full-process PLC control, frequency conversion control, touchscreen human-machine interface.

2. The feeding section uses universal wheels for easy use of the mechanical arm to load glass, and is equipped with automatic glass height detection with seamless connection to sections *3 and *4.

3. The section has a coating detection device, ensuring stable and reliable detection.

4. The gas-filling and pressing machine adopts four-axis servo linkage, integrating lamination, pressing, and inflation functions, ensuring that the argon content in insulating glass is ≥*5%.

5. High-power, high-wind-pressure fan, aluminum alloy air knife for fast drying.

6. The conveying and frame placing sections feature hollow and traceless design, with the upper crossbeam supporting glass transport to avoid glass marks. The frame placing section is equipped with lifting platforms in the front and rear for convenient use with large frames. The equipment is designed for user-friendliness, with rear access doors for maintenance.

7. Aluminum frame positioning uses industrial profiles with functions such as *0° right-angle positioning and adjustability.

8. External lamination is hydraulically controlled for smooth and reliable operation.

9. Brushes use imported materials, capable of cleaning coated glass, LOW-E glass, etc.

*0. Capable of producing extra-long, large, three-layer, and irregular insulating glass.

*1. The cleaning machine and water tank are entirely made of stainless steel and corrosion-resistant materials, providing excellent waterproof performance, safety, hygiene, and a long equipment lifespan.

*2. The cleaning air knife can automatically adjust according to the glass thickness.

*3. Each section of the production line's conveying parts features detection functions to prevent glass collisions and effectively reduce wear on glass transport wheels.

*4. The drying section implements dual air knives and double-circulating hot air to ensure effective glass drying, reduce noise, and the fan has sound insulation functionality.
