JS series 1500L good price good quality js1500 concrete batching plant By Zhengzhou jianxin machinery,

JS series 1500L good price good quality js1500 concrete batching plant

FOB Price

Get Latest Price

12800 ~ 17000 USD / Set

1 Set Minimum Order

Country:

China

Model No:

84743100

FOB Price:

12800 ~ 17000 USD / Set (Negotiable) Get Latest Price

Place of Origin:

China

Price for Minimum Order:

12800 per Set

Minimum Order Quantity:

1 Set

Packaging Detail:

1, For full container load, main body with plastic film surrounded or in nude, key parts and spare

Delivery Time:

Shipped in 7 days after payment

Supplying Ability:

100 Set per Year

Payment Type:

T/T, L/C, Money Gram, PayPal

Product Group :

concrete mixer

Product Specification

Brand Name: jianxin
Motor Power: 65kw
Mixing Power: 2*22kw
Charging Capacity: 2400L
Reclaiming capacity: 1500L
Speed of Mixing Drum: 19.5r/min
Water Supply Mode: water pump
Working Cycle Period: 60s
Discharge Way: automatic
Outline Dimension: 4720*2200*3000mm
Condition: New

model number:js1500
color:milk white ,dark green, yello or as request
Mixing blade quantity:2*8
lifting power:18.5 kw
output :90m3/h
Power type:Electric Engine
Product name:js1500 stationary concrete mixer
Max grain diameter(gravel/grait): 60/80

Product Description

The description of JS***0 concrete mixer
JS double horizontal shaft forced concrete mixer with different types of PLD batching machine composed of simple concrete mixing plant, or according to the needs of customers will JS series of mixer as a host to form a large mixing station, you can stir plastic, dry hard, liquid and other concrete.
As a result of its has received a lot of people's favor, there are JS***0, JS**0, JS**0, and other mandatory double-axis mixer, applicable to all types of large and small prefabricated components plant and roads, bridges, water conservancy, wharf and other large industries And civil construction works.
the features of js***0 concrete

Powdery materials are processed in hermetic condition in all procedures including loading, burdening, measuring, charging, mixing and discharging. There is a high quality dust remover in the main mixing pot, also the mixing pot and belt conveyor are sealed. Vastly reduced dust and noise pollution.
JS series henan ***0l js ***0 concrete mixer with winch has double mixing blades quantity compared with common twin shaft horizontal mixers. Outter ring pushes material to be boiling status, while inner ring shovel shears in radial direction, realize violent and sufficient mixing for material in a short time.
Electrical opening style or pneumatic discharging, avoid the shortcoming of raw material remaining.
Optimal designed hopper, easy to clean, better charging ability.
Reasonably designed with elegant appearance, quick assembling and disassembling, convenient transportation.

working principle of js***0 concrete mixer

•The break motor drives rotation of the coiling block, when the hopper climbs up to a certain height by loading track, the hopper door will open automaticlly, and raw materials will be put into the stirring pot.
•There are limit switches on loading shelf to assure the accurate position of the hopper. Js series hydraulic pump concrete mixer has 2 limit switches on upper limit positon, seperately offers positioning and protection for the hopper. Also there is 1 limit switch on lower limit position.
•The loading shelf of JS***0 concrete mixing machine can be folded for easy transport.
