Laboratory Internal Mixer Kneader Machine 1L/3L/5L

FOB Price

Get Latest Price

4800 ~ 30000 / Set

1 Minimum Order

Country:

China

Model No:

BP-8172-A-3L

FOB Price:

4800 ~ 30000 / Set (Negotiable) Get Latest Price

Place of Origin:

China

Price for Minimum Order:

4800 per Set

Minimum Order Quantity:

Packaging Detail:

Plywood Wooden Case

Delivery Time:

20 days

Supplying Ability:

100 Set per Month

Payment Type:

Other, PayPal, Western Union, T/T

Product Group :

Laboratory Internal Mixer

Contact Now

Dongguan Baopin Precision Instruments Co., Ltd.

China

Free Member

Contact Person Ms. May

Dongguan, Guangdong

Contact Now

Product Specification

white:yellow

Product Description

Product Description

This banbury laboratory rubber mixer is equipped with LED digital display with setting and value display output. And has different capacity to be selected. Can be used for formular research and development, testing of raw materials, etc.

The banbury laboratory rubber mixer is mainly used for the mixing the mixed rubber, plastics and industrial chemicals, and also used for the mixing of all kinds of low viscosity materials. And then put the formula into the production line.
(watch the video below)

Parameters

Mixing chamber volume	1L/3L/5L (optional)
Rotation angle	135°
Refuel method	Rotation
Rotor speed ratio	1:1.27
Vulcanization time	0.1 S ~ 99 m ~ 9.9 H mix time can be preset
Rotor speed	0-50rpm interver regulates the speed
Temperature range	Normal temperature~260℃
Air source pressure	0.5~0.8Mpa
Heating power	2.5KW
Power	8KW~15KW
Power supply	3 §,AC380V,22A

Specification

1.Heating method：Electro-thermal tube
2.Temp.Controller：LED digital display with setting and valuedisplay output
3.Feeding method：Rotation
4.Rotor material：SKD chrome-molybdenum alloy, surface treated by carburizing, chrome plating, polishing and other processes, rockwell hardness up to 60HRC.
5.Cooling method：It is cooled by tap water
6. Rotor type: Roller /Banbury /others ( optional )

Features

■Three sides of the mixing chamber are independent with mezzanine heating or connecting water-cooling tubes, meeting the process requirements of any milling and refined plastics.
■The surfaces of the mixing chamber contacted with the material are adopting high corrosion resistance and high wear-resistant material. With the processing of high frequency, carburization, hardening and tempering, chrome plating and polishing, it becomes hard and durable, hard to wear.
■Strong pneumatic arc pressure mound is matched with the end of mixing chamber. This chamber is of good sealing property and the mixing can be close to the real working environment.
■The speed motor drive of high pulling torque has an oval mixer shaft with two wings convex edges of lead angle. The angles are dislocated with opposite strength rotating and shearing, excellent mixing effect and efficient performance, significantly shortening the plasticate cycle.
■The electronic control system adopts appliances with authentic brands. The all-digital instruments can set and display all mixing parameters. The circuit rationing is in accordance with CE or higher standards with linkage action self-locking protection function and extensive application, safe and reliable.

Contact information

Whatsapp: +86 18938261793
Email:

Company profile

Dongguan Baopin Precision Instrument Co., Ltd. is the earliest manufacturer of experimental two roll mill and hydraulic press machine in China; it has over 25 years of experience.

In the plastic material and polymer material industry, Baopin Technology's rich product line covers all processing research areas, especially in the polymer new material application industry. Many of our scientific research technologies are in the leading position in China.

Baopin Technology has won more than 30 national patent technologies, its products have passed the EU CE certification, and passed the ISO9001:2015 quality management system certification. It is a high-tech enterprise recognized by the state.

Baopin Technology adheres to the business philosophy of quality; integrity; innovation, and works together with users to create a better future.
