QY series portable fully hydraulic core drilling rig

QY series portable fully hydraulic core drilling rig

1、Introduction of QY Series Portable Fully Hydraulic Core Drilling Rig

Fully hydraulic core exploration drilling rig adopts rope core drilling rig with full hydraulic power head drilling method, and the core drilled by the drilling tool is lifted out by the winch through the inner hole of the drill pipe to complete the geological drilling core work. It is mainly suitable for drilling solid ore deposits, and can also be used for engineering geology, shallow oil, natural gas, groundwater drilling, and engineering drilling such as tunnel ventilation, drainage and dike grouting.

2、Features of QY Series Portable Fully Hydraulic Core Drilling Rig

2.1 Modular design, light weight, easy to disassemble and carry.

2.2 The rig is fully hydraulic driven, and the hydraulic system adopts load sensitive control, with high working efficiency and high torque.

    2.3 The power head rotation is driven by axial piston pump and inclined shaft piston motor, and the mechanical two gears plus step less speed regulation, advanced structure.

2.4 Equipped with a lateral translation mechanism for the power head, the mast is raised and lowered by a cylinder and can slide as a whole, and can drill holes within the range of ****0°.

2.5 Hydraulic gripper to achieve clamping drill pipe, with drill pipe disassembly.

2.6 Hydraulic motor driven hoist, can be flexible lifting drilling tools or auxiliary tools.

三、Parameters of QY Series Portable Fully Hydraulic Core Drilling Rig

Drilling rig model QY***0 QY***0 QY****0

Drilling capacity BTW **0m **0m ***0m

  NTW **0m **0m **0m

  HTW **0m **0m **0mm

  PQ / / /

Hydraulic system Rated pressure *0mpa *0mpa *0mpa

  cooling mode water cooling water cooling water cooling

Engine Engine type Yunnei Yunnei Yunnei

  Rated power *5kW*2 *8kW*3 *5kW*3

Power head Maximum torque ***0N.m ***0N.m *******0N.m

  Maximum rotate speed ***0rpm ***0rpm ***0rpm

  Feeding stroke ***0mm ***0mm ***0mm

  Lifting force **0kN **0kN **0kN

  Propulsion force *5kN *5kN *0kN

Wire-line coring winch Rope capacity **0m **0m ***0m

  Lifting force *5kN *5kN *4kN

  Lifting speed **0m/min **0m/min **0m/min

Mast parameters Full height 5.8m 5.8m 5.8m

  Drilling angle ****0° ****0° ****0°

Transport size L*W*H 3.8*1.5*1.3m 4.8*1.5*1.3m 5.6*2.0*1.3m

Whole machine weight 1.6T 2T 2.3T

Note: Products are constantly being improved. Any changes will not be notified separately. Please refer to the actual product.
