Rubber Track Remote Operated Slope Mower (VTLM800)

FOB Price

Get Latest Price

1100 ~ 2700 USD / Set

|

1 Set Minimum Order

Country:

China

Model No:

-

FOB Price:

1100 ~ 2700 USD / Set Get Latest Price

Place of Origin:

China

Price for Minimum Order:

1100 per Set

Minimum Order Quantity:

1 Set

Packaging Detail:

wooden case

Delivery Time:

15

Supplying Ability:

100000 Set per Year

Payment Type:

-

Product Group :

-

Contact Now
Free Member

Contact Person Judy

Contact Now

Product Specification

  • Color:Black

Product Description



We are a manufacturer which focuses on the production of remote control grass cutter lawn mowers only. Compared with many other companies which do not produce their own but sell consignments, we do have obvious advantages in product research and development. Our products perform exceptionally well due to state-of-the-art technology and high-tech configurations. Compared with similar products, our price advantage is significant. Based on the in-depth understanding of products, we provide the best quality and efficient after-sales services which can directly help customers solve product problems online and provide fast technical support.



VTLM800

Model No. VTLM800

General Parameter



Type Crawler
Working Speed 0~4km/h
Working Degree 0-60°
Cutting Height 10~180mm (remote control)
Cutting Width 800mm
Start Method
a. Electric start
b. Remote control star

Engine



Engine/Power Loncin 16Hp
Emission 452CC
Fuel Tank 7L
Working Time 4h

Working Motor

Voltage/Power Electric traction
Voltage/Power 48V / 1000W
Motor Type Brushless electric traction

Dynamo



Dynamo 56V 4000W

Battery



Battery 48V 20Ah

Weight



Machine Weight 235kg





Gasoline Engine

452CC Loncin meets both Euro 5 emission standards and international EPA certification. It's equipped with an oil pump, ensures that the engine receives a constant supply of pressurized oil for effective lubrication, particularly during the demanding conditions of driving on a slope.

    Servo Motor

   Vigorun servo motor's coil frame and enameled wire are all made of high-temperature resistant materials. The matching servo motor driver has encoder control and comes with electric braking and axle lock functions. It ensures that the motor remains stationary on slopes without slipping.

Warning Light

The warning light turns on when the lawn mower is powered on, which can effectively protect the safety of people, pets, etc.





Worm Gear& Worm Reducer

Worm gear reducer, as a traditional transmission device, consists of a worm wheel and a worm, with involute teeth profile. Its advantages include compact mechanical structure, lightweight and small size, efficient heat dissipation, easy installation and maintenance, high transmission ratio and torque capacity, smooth operation, low noise, durability, versatility, and suitability for lifting operations. It also has a long service life and a wide range of speeds for large-scale speed reduction. Moreover, it possesses self-locking capability.

Dynamo

We use a 56V 4000W dynamo with a large capacity battery of 12V 20Ah* 4PCs for this VTLM800 model. This combination can effectively ensure that the machine can continuously mow grass for a long time. Brushless, expensive, but there is no need to change the carbon brush later, and the service life is long. Better bearings are used, with less friction, less waste and high conversion rate.





Servo Motor Controller

Vigorun servo motor controller is a servo control system, offering superior performance compared to other drivers on the market. The dual-channel servo motor driver ensures excellent synchronization, enabling straight-line movement, which is challenging to achieve with other controller.

Mower Blades

The blades are made of resilient and durable manganese steel material. The cutting edge of the blades is serrated, which prevents dual-channel servo motor drivermowing,especially fresh grass.

Rubber Truck

15cm wide rubber track Crawler tank design, can work normally below 60 degree slope. The inside of the track adopts a steel frame structure. and the design of the external rubber track conforms to engineering principles, which is wear-resistant and durable.













This photo shows our product customization service. We will provide you with professional guidance and advice to help you make your own best lawn mowers.The minimum order quantity for customized products is 10 units.

We have advanced laser engraving technology to create complex geometric shapes. So the logo and pattern can be customized as required. You may design your own logo and brand name.We can make it on the machine.





radio controlled track lawn trimmer for sale

remote operated wheeled brush cutter for sale

RC wheeled tank lawn mower for sale







It is widely used in community greening, ecological garden, ecological park, embankment, farm, field weeds, football field, forest, forest farm, front yard, garden lawn, gardens, golf course, greenhouse, greening, high grass, highway plant slope protection, hillside, mountain slope, orchards, pastoral, patio, reed, residential area, river embankment, river levee, roadside, ugby field, sapling, shrubs, slope, slope embankments, soccer field, steep-incline, swamp, terracing, thick bush, vegetables, villa lawn, wasteland, weeds, wetland, wild grassland.
