SHINHO X-86 ARC Optical Fiber Fusion Splicer

Product Description

Product features
-PAS image digital processing system,core to core alignment;
-The arc is calibrated by the environmental parameters as tempeture and pressure;
-Variety display group,the Maximum image magnification is **0;
-Typical splicing time is 8 second,*8 second heating;
-Metro style GUI,easy to operate;
-Intelligence operate,auto heat or work when open the shield;
-High definition 5.7' colorful LCD;
-Hight to ***0 groups fusion records can be stored;
-Rubber armor protect machine body from shock or impact;
-High capacity,plug batteru,long work time;
-Software can be upgraded through USB port.

Product specification
Applicable fiber type:SM, MM, DS, NZDS
Diameter of cladding:*0 ***0um
Diameter of coating:**0 - **0um
Typical fusion loss:SM 0.*2dB,MM 0.*1dB,NZDS 0.*3dB, EZ-Bend 0.*4dB
Return loss:Better than *0dB
Operate mode:Manual,Automatic
Auto-Heat:Available
Typical fusion time:Less than 7s
Heating time:*8 seconds for *0mm,*0mm length heat shrinkable sleeve
Magnification:**0 times for X|Y single display,**0 times for XY double display
Photoelectric system:Two high sensitive cameras,5.7’**0×**0 pixel colorful LCD
Fusion data record:Store ***0 groups fusion record
Battery capacity:***0mAh,**0 times of fusion and heating,hot plug
Electric pole lifetime:More than ***0 times fusion,user can replace pole conveniently
External port:USB2.0 port,used to derive fusion record data ,software upgrade
Operate environment:Altitude;0~***0m;Relative humidity:0~*5%;Temperature:**0°C~**0°C;Wind speed:max *5m/s
Volume/Weight:**0mm(L)***0mm(W)***5mm(H) / 2.*5kg

After-sales Service
We guarantee all our fusion splicers for one year from the date customers receive them. Other parts for six months.We guarantee that every fusion splicer is tested carefully and works very well before shipment. We strive for **0% customer satisfaction on every sale we complete.We are responsible for the whole lifespan of our products, and whenever you have questions during usage, feel free to contact us, we are glad to provide technical support timely.

Lifelong Maintenance Service
During the warranty period, we can repair or replace the defective parts for free.After the warranty time, we can also repair the defective parts, but only charge for parts.
