Product Description

Product name: SSAW Steel Pipe,Spiral Submerged Arc Welding Steel Pipe,Spiral Steel Pipe, SAWH pipe
Outside diameter: *******8mm
Wall thickness: ***5mm
Length: ****0m
Standard: API 5L, ASTM A**2, EN******1, EN******2, EN ****7, GB/T***1.1, GB/T***1.2
Material Grade: GR.A, GR.B, GX*2,X*2,X*0,X*5,X*0,X*0. Q**5,Q**5B, and so on.
Technique: Double sides submerged arc welding steel pipe



​Spiral Weld Pipe, as the name implies, is a steel pipe that has a seam running its entire length in a spiral form.
In the past, due to the method of manufacture, Spiral Welded pipe was relegated to low pressure and structural applications. With the development of the Submerged Arc Welding process, the production of large hot rolled coils of sufficient width and the development of dependable non-destructive testing methods, it is now possible to produce Spiral Weld pipe for high-pressure service.
Present Spiral Weld mills consist of a de-coiling device (in the case of strip base material) or a plate preparation table (where the base material is in plate form) a strip connecting welder, straightening rollers, edge preparation tools (shearing and trimming), prebending devices, a three roller bending and cage forming system, an internal welder, an external welder (both Submerged Arc), ultrasonic testing apparatus and cutting devices.
The material passes through all these production stages continuously. The angle between the flat strip being fed into the machine and the finished pipe leaving the machine controls the pipe diameter in ratio to strip width and the angle of the weld in the pipe.
Because of the method of manufacture, a wide variety of diameters can be produced. The diameter tolerance is small, particularly with regard to ovality; and the pipe, due to its axial symmetry, has an inherent straightness. The length range is infinite and is controlled only by the economics of transportation.
Spiral Weld Pipe is used for dredging, slurry, water and other pipelines, as well as piling and structural applications.
Spiral Weld Pipe is produced in accordance with the dimensional and tolerance requirements of various ASTM, AWWA, and API



SSAW Steel Pipe, Spiral Submerged Arc Welding Steel Pipe, Spiral Steel Pipe, SAWH pipe, helical pipe, SAW Piling Pipe, Pipe Pile, Water line pipe, Large pipe, long pipe,API, ASTM, EN, BS,JIS, Steel pipe, Annealing Welded pipe, Cold drawn, hot rolled, steel tube, Iron pipe, manufacture, mill, factory, xingang, tianjin, China



Specifications.
The spiral welded pipe machinery supplied from Germany has an advanced PLC system controlling all main functions, modified Lincoln automatic DC**-AC tandem submerged arc welding for both inside and outside which enhances the productivity and improves the welding quality. The machinery is equipped with an automatic strip centering system, strip edge milling and pre—bending system, automatic weld gap control, automatic centering device for the internal welding, TV camera and monitor for external welding, digital displays of the main drive speed(welding speed), an wire feeding speed and a flux feeding/recovery system, which are sshighly automated for ease of operation.​​
