Super 1800c U shape Pure Mosi2 Heater Heating Elements

Product Description

U Shape Mosi2 Heating Elements

The U shaped mosi2 heating elements are most frequently used suspended with the bottom of the "U" down. The element consists of two cold ends (Lu) and a U-shaped hot section (Le).

The cold ends are twice the diameter of the hot section and are attached by a weld. The extremities of the cold ends are metallized with aluminum to provide a low-resistance contact surface to which the electrical connections are made with flat braided aluminum straps.





Standard specification



Two-Shank Elements

Manufactured to industry established diameters and resistance values in the following diameters: 3/6, 4/9, 6/*2, 9/*8 and *2/*4.

Mosi2 heating element length:Lu length from **0 to ***0mm,Le length from **0 to ***0mm,customized is available.

MoSi2 heating element operation temperature: from **0C to ***0ºC. Max temperature can up to ***0 ºC

MoSi2 heating element rod shape: U type; W type; straight type; L type.





1. Transition section (g) should be inserted inside the furnace, to avoid the case that heat can not emit and resulting in damage of the transition section.
2. When installing, it is necessary to keep certain distance between the U shape mosi2 heating element and furnace bottom (h).
3. Make sure a reasonable distance between the U shape mosi2 heating element and furnace wall.
4. The suggest surface load of ***0 type U shape mosi2 heating element and furnace wall under ***0 C furnace temperature is below *3. 5w/cm3. The suggest surface load of ***0 type U shape mosi2 heating element under ***0ºC furnace temperature is below *1. 5w/cm2. And the suggest surface load of ***0 type products under ***0 C furnace temperature is below *2 w/cm2.
