Ultrasonic Domestic Gas Meter

FOB Price

Get Latest Price

60 ~ 170 USD / Unit ( Negotiable )

1 Unit Minimum Order

Country:

China

Model No:

G1.6/G2.5/G4

FOB Price:

60 ~ 170 USD / Unit ( Negotiable )(Negotiable) Get Latest Price

Place of Origin:

China

Price for Minimum Order:

60 per Unit

Minimum Order Quantity:

1 Unit

Packaging Detail:

Delivery Time:

Supplying Ability:

60000 Unit per Year

Payment Type:

T/T

Product Group :

Ultrasonic Gas Meter

Contact Now

Zhengzhou Anran I&C Technology Co., Ltd.

China

Free Member

Contact Person Ms. Amy

The National University Science Park, No.11, Changchun Road, High&New Technology Development Dis, Zhengzhou, Henan

Contact Now

Product Specification

white:blue

Product Description

Description

Ultrasonic gas meter is a fully electronic speed metering device developed and produced by our company that uses ultrasonic measurement. It is characterized by non-contact, no moving parts, large range ratio, good linearity, high reliability and high measurement accuracy.

Key Strengths

Low pressure absorption
No mechanical wear
Good repeatability
Ultra compact
No moving parts
High measuring precision with more stationary error curve
Temperature and pressure compensation
Stable operation and long service life without noise
Non-magnetic element and measurement not easily affected by magnetic field

Key Technologies

Large range ratio
Small starting flowrate
Two-way measurement
Fault self-detection
Valve shut-off due to overflow

Specification

Type	G1.6	G2.5	G4
Qmax (m3/h)	2.5	4	6
Qmin (m3/h)	0.**6	0.**5	0.*4
Qstart (dm3/h)	3	5	5
Range ratio	**0:1
Accuracy class	1.5
Working voltage	6V
Battery	AA alkaline battery (NO. 5)/ lithium battery 3.5V
Working temperature	﹣5℃～0℃
Maximum working pressure	*0kPa
Average working current	≤1mA
Quiescent current	≤*0μA
Pressure absorption	≤**0Pa
Meter fittings central distance (mm)	**0
Degree of protection	IP*5
ATEX	ExibII BT3 Gb
Measuring resolution	0.**1m³
Valve durability	>****0 cycles
Temperature and pressure compensation	Optional
