Main Features Of Thickness Gauge XY-260
1.Can equipped with various double crystal probes of different frequency and different
wafer size.
2.With functions of the probe zero calibration,automatically correcting errors of the
system.
3.Of known thickness can be measured speed of sound, in order to improve the measurement accuracy.
4.With EL backlit, convenient use in dim light.
5.With RS232 interface and can be easily and quickly exchange data with PC, can be
connected to the micro printer.
Technical Parameters
| No. | Items | Indicators | |
| 1 | Display method | High contrast segment LCD, high brightness EL backlight | |
| 2 | Measurement Range |
(0.75 ~ 300) mm (steel), metric and imperial freely convertible |
|
| 3 | Velocity range | (1000 ~ 9999) m / s | |
| 4 | Resolution | 0.1mm/0.01mm optional | |
| 5 | Indication accuracy |
± (0.5% H +0.05) mm; H is the actual thickness of the measured object |
|
| 6 | Measuring cycle |
|
|
| 7 | Storage capacity | 20 groups (up to 100 measurements/group)thickness measurement data | |
| 8 | Operating modes |
Two modes: a single point thickness measurement, scanning thickness measurement mode |
|
| 9 | Unit system | Metric or imperial (optional) | |
| 10 | Working voltage | 3V (2 AA-size alkaline batteries) | |
| 11 | Continuous working time | More than 100hours (without backlight) | |
| 12 | Communication interface | RS232,with the micro printer or PC connection | |
| 13 | Overall dimension | 150mm*73mm*31 mm | |
| 14 | Weight | 185g |
| Country: | China |
| Model No: | XY-260 |
| FOB Price: | ( Negotiable ) Get Latest Price |
| Place of Origin: | - |
| Price for Minimum Order: | - |
| Minimum Order Quantity: | 1 Piece |
| Packaging Detail: | box |
| Delivery Time: | 10 days |
| Supplying Ability: | 20 Piece per Day |
| Payment Type: | T/T |
| Product Group : | Ultrasonic Testing |
