Wall form column form

Product Description

VINCI is a steel frame formwork system composed of high strength rectangular tube profiles, which could be easily combined with TAMON *0 panel locks. The steel frame profiles are designed to be able to connect at any point with the other panel. Panel facing is the plastic coated Birch Plywood namely WISA‐Form Elephant (delivered by UPM), providing higher durability and longer life.

Panel widths are *0, *5, *0, *5, *0, **0, **0cm. whereas the heights are chosen as **0, **0, **0, **0, **0 and **0cm. The panel corners bear solid steel pieces which gives extra stiffness while also delivering strong inserts for levering and lifting holes for handling. Only the solid corner would double the panel life against similar systems.

TAMON formwork lock could be applied to any point on the frame profiles as well as transversals. The conical holes for DW*5 tie‐rods on panel are so positioned that formwork bears *0 kN/m2 concrete pressure. The formwork system consist of VINCI panels, Tamon locks, SAH tie‐rods, VINCI crane hooks, VINCI type cat‐walk brackets, double push‐pull props and accessories.
