Waste to oil/waste plastics rubbers tires pyrolysis plant from Jiaozuo Zhongli

Product Description

Waste to oil/ waste plastics rubbers tires pyrolysis plant from Jiaozuo Zhongli

1.The main parts and the function of the pyrolysis machine

a) The reactor

The raw materials are pyrolyzed in the reactor,it is **5R boiler steel.the thickest part could be *6mm.It works doesn't like the traditional way that we burn something,we make the waste pyrolyzed at certain temperature,so it without air or water.In a word,it has the same function to kiln,so I think its your point.

b) Oil reacting tank

The first step to deposit the waste in the tyre gas to make sure the clearness of oil.

c)Gas separate

The impurities will be deposited at the bottom of the gas separate.

d)Depositing tank

The second filter,so that the oil gas will be refined.

e)Cooling pool

The oil gas will be cooled down in the cooling pipes of the cooling pool.

f)Oil tank

It can store the crude oil.

g) mpact duster collector

The first step to purify the waste in the air.

h)Water film cyclone

The second step to clean the waste in the air.

i)Chimney

The white smoke without pollution will release into the air from the chimney.

2.The advantages of our machine

a) the material of the reactor is *6mm boiler plate,and its more useful than the *2mm and *4mm one.

b)The cooling tubes we use is *0tubes,the diameter is **0mm,no jamming concerns and easy to maintenance.

c)The horizontal cooling pool without electricity machine can save more electricity than vertical one.

d)3 parts to clean the waste in the gas,no pollution to the environment.

e)Recycling the waste gas as fuel to burn after 2hours.

f)Big draft fan take away the smoke slao keep the temperature in the reactor.

g)With safety valve to control the pressure to make sure the safety.

3.Final products:

Tires oil: widely used as fuel oil in industries such as steel and iron factories ceramics or chemical

                industrie or hotels restaurants etc.or used for generators to get electricity

Carbon black:used for construction bricks with clay

                         also can be used as fuel

                         also can be deep process

Steel wires:sold or reprocessing

Combustible gas:can be recycled or used during processing as fuel.

4. Other product:

Expect  pyrolysis plant, the oil refinery plant, tire shreeder machine, tire recycling machine, quantitative packing machine and grain sorting machine can be offered by us. More details, welcome to consult by the following contact ways:

5.Contact ways:

More details, welcome to consult by these following ways:

Jiaozuo Zhongli New Energy Equipment Manufacturing Co.,Ltd.

Wanfang Industrial Zone, Macun District,Jiaozuo City, Henan Province, China

Amanda Zhao

Tel:**************8

Mobile Phone: ************4

Skype:amanda_jzzhongli

Whatsapp:************4
