EL3154

Product Description

• Manufacturer:

• Product Number: EL***4

• Product Type: EtherCAT Terminal, *-channel analog , current, 4…*0 mA, **-bit, single-ended

• Number of s: 4 (single-ended)

• Technology: single-ended

• Signal type: single-ended

• Signal current: 4…*0 mA

• Distributed clocks: yes

• Internal resistance: typ. *5 Ω + diode voltage

• Input filter limit frequency: 5 kHz

• Dielectric strength: max. *0 V

• Conversion time: ~ **0 µs

• Resolution: *6 bit (incl. sign)

• Measuring error: < ±0.3 % (relative to full scale value)

• Electrical isolation: **0 V (E-bus/signal voltage)

• Current consumption power contacts:

• Current consumption E-bus: typ. **0 mA

• Bit width in the process image : s: *6 byte

• Configuration: no address or configuration setting required

• Special features: standard and compact process image, activatable FIR/IIR filters, limit value monitoring

• Weight: approx. *0 g

• Operating/storage temperature : **5…**0 °C/**0…**5 °C

• Relative humidity: *5 %, no condensation

• Vibration/shock resistance: conforms to EN ********6/EN *********7

• EMC immunity/emission: conforms to EN ********2/EN ********4

• Protect. rating/installation pos. : IP*0/variable

• Pluggable wiring: for all ESxxxx terminals

• Approvals/markings: CE, UL, ATEX, IECEx, cFMus

• Ex marking :

  • ATEX: II 3 G Ex nA IIC T4 Gc

  • IECEx: Ex nA IIC T4 Gc / Ex tc IIIC T**5 °C Dc

  • cFMus: Class I, Division 2, Groups A, B, C, D / Class I, Zone 2, AEx ec IIC T4 Gc

• Design form: compact terminal housing with signal LEDs

• Material: Polycarbonate

• Dimensions (W x H x D) : *2 mm x **0 mm x *8 mm

• Installation: on *5 mm DIN rail, conforming to EN ****5 with lock

• Side by side mounting by means of: double slot and key connection

• Marking: labeling of the BZxxx series

• Wiring: solid conductor (e), flexible conductor (f), and ferrule (a): spring actuation by screwdriver

• Connection cross-section :

  • s*: 0.*8…2.5 mm²,

  • st*: 0.*8…2.5 mm²,

  • f*: 0.*4…1.5 mm²

• Connection cross-section AWG :

  • s*: AWG *8…*4,

  • st*: AWG *8…*4,

  • f*: AWG *6…*6

• Stripping length: 8…9 mm

• Current load power contacts : Imax: *0 A

  *s: solid wire; st: stranded wire; f: with ferrule

• Shipping weight: 2 kg
