High Voltage Solar Fuse Holder 1500VDC Din Rail Mount Fuse Holder For Solar System Protection

FOB Price

Get Latest Price

4.8 ~ 3.26 USD / Piece

|

100 Piece Minimum Order

Country:

China

Model No:

NSPV-63T

FOB Price:

4.8 ~ 3.26 USD / Piece Get Latest Price

Place of Origin:

China

Price for Minimum Order:

4.8 per Piece

Minimum Order Quantity:

100 Piece

Packaging Detail:

Standard packing

Delivery Time:

15-20 working days

Supplying Ability:

10000 Piece per Month

Payment Type:

Other, T/T

Product Group :

Solar fuse holder

Contact Now
Newsun PV Technology CO., LTD

Newsun PV Technology CO., LTD

China

10888 Trust Points
1st Year

Contact Person Mr. bill

Changan, Dongguan, Guangdong

Contact Now

Product Specification

  • Product :Solar fuse holder
  • Color:White
  • Application:Widely used
  • Fuse type:NSPV suggested
  • Quality:Excellent
  • Fuse size:10x85mm

Product Description

1500VDC Fuse Holder NSPV-63T
Product Specifications
Insulation material PA Flame class UL94-V0
Rated current 50A Ambient temperature range -40℃…+85℃(IEC)
Rated voltage 1500VDC Suitable cable cross sections 1.5~16mm2 /16~16AWG
Test voltage AC3kV(50Hz,Imin) Connecting system Crimp connection
Contact resistance ≤0.25mΩ Nut cap locking force 1.8Nm
Contact material Copper,Tin plated Upper limiting temperature 125℃(IEC)
Insulation resistance ≥500Vdc 1000MΩ Rail spec. TH35


Country: China
Model No: NSPV-63T
FOB Price: 4.8 ~ 3.26 / Piece Get Latest Price
Place of Origin: China
Price for Minimum Order: 4.8 per Piece
Minimum Order Quantity: 100 Piece
Packaging Detail: Standard packing
Delivery Time: 15-20 working days
Supplying Ability: 10000 Piece per Month
Payment Type: Other, T/T
Product Group : Solar fuse holder
