RF Power Amplifier 2-18GHz
10W/50W Solid State SMA Connectors Customized
Manufacturer
Product
description
The module is
designed for both military and commercial applications. The latest
device technologies and design methods are employed to offer high
power density, efficiency, and linearity in a small,
lightweight
Specification
Typical performance
at +40VAC +25oC, and in a 50Ω system.
| RF / ELECTRICAL | ||||
| PARAMETER | MIN | TYP. | MAX | UNIT |
| Operating Frequency | 2000 | 18000 | MHz | |
| RF INPUT | 0 | 5 | dBm | |
| Power Gain | 47 | dB | ||
| P-sat Output Power | 50 | W | ||
| PowerGain Flatness | ±3.5 | dB | ||
| In/Out Impedance | 50 | Ω | ||
| Spurious Signals | -50 | dBc | ||
| Harmonic Signals | -10 | -8 | dBc | |
| Operating Voltage | 40 | V DC | ||
| Supply Power | 1000 | W | ||
| Input VSWR | 2 | 2.5 | ||
| MECHANICAL | ||
| PARAMETER | VALUE | UNIT |
| Dimensions (W x D x H) | 400*300*90 | mm |
| RF Connectors (Input / Output) | SMA-KF / SMA-KF | -- |
| Control Connector | D-SUB：Power on/power off control; Monitoring parameters include output power, temperature | -- |
| Cooling | Exteral Heatsink Required | -- |
| Weight | ≤10 | kg |
| Connector Definition | ||
| AMPLIFIER CONNECTOR TYPE: | D-SUB | |
| TRIAD CABLE PART NUMBER: | —— | |
| NUMBER | Definition | DESCRIPTION |
| 1 | VDD | 40V |
| 2 | VDD | 40V |
| 3 | GND | GND |
| 4 | GND | GND |
| 5 | PA Enable | TTL Hi= Enable, TTL Lo = Disable or No Connection |
| 6 | Alarm | Alarm (TTL) |
| 7 | Temp monitoring | Temperature (Analog) |
| 8 | NC | NC |
| 9 | NC | NC |
