Rke Vision Aoi for Rubber Ring Full Automatic CCD Vision Inspection Optical Sorting Machine Device

FOB Price

Get Latest Price

1 Minimum Order

Country:

China

Model No:

FOB Price:

(Negotiable) Get Latest Price

Place of Origin:

China

Price for Minimum Order:

Minimum Order Quantity:

Packaging Detail:

wooden package

Delivery Time:

40 working days

Supplying Ability:

Payment Type:

T/T, Western Union

Product Group :

Contact Now

DONGGUAN RKE INTELLIGENT TECHNOLOGY CO., LTD

China

5000 Trust Points

1st Year

Contact Person Ms. Tale

Dongguan, Guangdong

Contact Now

Product Specification

Product Description

Basic Info.

Model NO.

RK1500

Certification

GS, CE, ISO9001

Condition

New

Application

Electronic Component, Auto Part, Drug, Plastic, Seals, Nail, Bolt, Blind Nut, Nut, Screw

Lens Number

Type

Glass Disc

Transport Package

Wooden Package

Specification

RKE-1900

Trademark

RKE

Origin

China

HS Code

9031499090

Production Capacity

200 Pieces/Month

Product Description

RKE AOI machine , for rubber o -ring products vision inspection , and automatic optical sorting machine, this machine adopts vibration disc feeding, equipped with artificial intelligence visual inspection software, and equipped with 8 CCD industrial cameras. According to customer requirements, it can detect whether the key dimensions of the product, such as inner diameter, outer diameter, height, etc., meet the drawing requirements, as well as whether the surface of the product has appearance defects such as material shortage, pits, white spots, etc. The detection speed is 200pcs/min, and the detection accuracy is ± 0.01mm. According to customer requirements, it is equipped with an automatic packaging machine to complete automatic counting, labeling, packaging and other functions!

Rke Vision Aoi for Rubber Ring Full Automatic CCD Vision Inspection Optical Sorting Machine Device

Thank you for your trust in RKE Intelligent Technology Co., Ltd. We will provide you as following:
Item	Specification
Optical Sorting Machine RK-1900-C8	Inspection Component: size / appearance defective Camera : Hi-Vison Color CCD (200w) *Light Source: RGB cascade multi-angle LED combination lighting, high brightness, 2M pixels tele-centric lens, 5050mm Motor:Japan Panasonic Computer: Dell 2.7G, DDR II 2.0G, 500G , 19" wide screen LCD Software: RKE self-developed(based on labview) Solenoid valve: American Newmandick solenoid valve Power: 220V/50Hz ,1000W Accuracy : ± 0.01mm Detect Speed : 200pcs/min Machine size: 150013001860(2150)mm,Weight: 355KGS Vibrating Device size: 6508001350mm, Weight: 255kgs**

Country:	China
Model No:	-
FOB Price:	(Negotiable) Get Latest Price
Place of Origin:	China
Price for Minimum Order:	-
Minimum Order Quantity:	1
Packaging Detail:	wooden package
Delivery Time:	40 working days
Supplying Ability:	-
Payment Type:	T/T, Western Union
Product Group :	-
