Semi-Automatic Access Control System

Product Description

Access Control Tripod Turnstile Gate TEB-E215

Main Features:
1 Stainless steel housing
2 Bi-direction pass
3 Arms auto drop when power off
4 Arms auto rise up when power on and auto stop on abstacle
5 Traffic light indicator
6 no RFID interface
7 Photoelectric inspection
8 RS232 socket,  LAN socket
9 Passenger counter (optional)
10 If the passenger does not pass in the valid time,  the passenger will be locked up again.. the valid passing time can be set up by operator.

Specifications:
Power consumption 50W
Housing Size 420*330*980mm
Housing material 2mm,  201/304# stainless steel,  corosion resistant
Drive motor NA
Channel width 500--600mm
Pass speed ≤ 40 persons/min.
IP protection IP44
Input singal optional DC12V/dry/contact/RS485/RS232/
railing-off against power off Yes
Working enviroment temperature minors -10°C to 50°C
Working environments indoor, outdoor
Relative humidity ≤95% coagulation free
MCBF 1, 000, 000 cycle

LED Counter


Application:
Tripod turnstile is your ideal choice for entrance control and widely applied in:Community,  school,  bank,  seabeach,  shopping center and so on.
Other place:
1. Industrial zones
2. Administrative buildings
3. Recreation centers
4. Amusement parks
5. Financial institutions
6.Government agencies
7. Airports
8. Bus and railway stations
9. Offices.
