FOB Price
Get Latest Price( Negotiable )
|1 Unit Minimum Order
Country:
China
Model No:
XG955H XG958H XG955N XG956N XG958N XG968N
FOB Price:
( Negotiable ) Get Latest Price
Place of Origin:
china
Price for Minimum Order:
-
Minimum Order Quantity:
1 Unit
Packaging Detail:
optional
Delivery Time:
optional
Supplying Ability:
15 Unit per Month
Payment Type:
Other, PayPal, Money Gram, Western Union, D/P, D/A, L/C, T/T
Product Group :
Contact Person Mr. Ryan
Yangpu, Shanghai, Shanghai
| Specification | ||
| Manufacturer | XGMA | |
| Model | XG955H | |
| Overall length(mm) | 7710 | |
| Overall height(mm) | 3450 | |
| Overall width(mm) | 2880 | |
| Wheel base(mm) | 2880 | |
| Ground clearance(mm) | 500 | |
| Tread(mm) | 2240 | |
| Bucket Width (mm) | 3000 | |
| Turn radius(mm) | 5775 | |
| Min.Turn radius outside of bucket (mm) | 6650 | |
| 4120 | ||
| Max. Dumping Height(mm) | 3215 | |
| Dumping Reach(mm) | 1185 | |
| Digging depth(mm) | 80 | |
| 47 | ||
| Engine model | SC9D220G2B1/SC11CB220G2B1/6CTA8.3-C125/WD615 | |
| Rated power (kw) | 162/162/160/162 | |
| Fuel comsumption per hour(g/kw.h ) | 220/225/229/205 | |
| Rated speed (r/min) | 2200/2200/2200/2200 | |
| Max torque(N.m) | 880/844/908/850 | |
| Operating Weight (Tonnes) | 17.2 | |
| Rated Load(Tonnes) | 5 | |
| Bucket capacity (m3) | 2.2-3.6 | |
| Lifting time/Lifting, dumping and lowering(s) | 5.8/11 | |
| Max Breakout force(KN) | 170 | |
| Max. turning angle(°) | ±35° | |
| Fuel tank（L） | 220 | |
| Hydraulic tank（L） | 295 | |
| Working pressure of steering hydraulic system(MPa) | 15 | |
| Working pressure of load hydraulic system(MPa) | 16 | |
| Travel speeds（km/h） | FORWARD 1ST | 0～11.5 |
| FORWARD 2ND | 0～38 | |
| FORWARD 3RD | — | |
| FORWARD 4TH | — | |
| REVERSE 1ST | 0～16 | |
| REVERSE 2ND | — | |
| REVERSE 3RD | — | |
| Gear Box | XG | |
| Axle | XG | |
| Implement pump | 209 | |
| Distibuting valve | D32 | |
| Steering Hydraulic system | BZZ6-1000 | |
| Steering pump | 143 | |
| Tyre size | 23.5-25-16PR | |
| Air Conditioning/Anti-mist when idleing | √ | |
| Heating | √ | |
| Radio/Cassette | √ | |
| Bucket and arm raiseing (limit height) Device | √ | |
| Hydraulic Operation system | √ | |
| Electricial Monitor and alarm system | √ | |
| Seat Buckle | √ | |
| Head lamp | √ | |
| Reversing Alarm (Back vehicle) | √ |
(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.
(2)Spare parts:CANMAX is dedicated to provide our clients
with genuine spare parts with the highest quality,exact fitness
and appropriate function.
(4)Training: CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.
(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.
| Country: | China |
| Model No: | XG955H XG958H XG955N XG956N XG958N XG968N |
| FOB Price: | ( Negotiable ) Get Latest Price |
| Place of Origin: | china |
| Price for Minimum Order: | - |
| Minimum Order Quantity: | 1 Unit |
| Packaging Detail: | optional |
| Delivery Time: | optional |
| Supplying Ability: | 15 Unit per Month |
| Payment Type: | Other, PayPal, Money Gram, Western Union, D/P, D/A, L/C, T/T |
| Product Group : | Wheel Loader |
