FOB Price
Get Latest Price4.5 ~ 3.5 / Piece ( Negotiable )
|Minimum Order
Place of Origin:
-
Price for Minimum Order:
Minimum Order Quantity:
1000 Piece
Packaging Detail:
Standard packing or according to customer's request.
Delivery Time:
10-15days
Supplying Ability:
10000 Piece per Month
Payment Type:
Other, PayPal, Western Union, T/T
Contact Person Mr. bill
Changan, Dongguan, Guangdong
| 1500VDC PV 4.0 Fuse Connector 4F1-15+4F2-15+4F3-15 | |||||||||
| Product Specifications: | |||||||||
| Insulation material | PPE/PA | Fuse Specification | 1A-50A | ||||||
| Rated current（Without fuse） | 50A | Safety degree | II | ||||||
| Rated voltage | 1500VDC | Flame class | UL94-V0 | ||||||
| Maximum voltage（With fuse) | 1575V | Ambient temperature range | -40℃…+85℃(IEC)* | ||||||
| Contact resistance | ≤0.25 mΩ | Upper limiting temperature | 110℃(IEC) | ||||||
| Contact material | Copper,Tin plated | Suitable cable cross sections | 2.5~10mm2
/14~8AWG (4F1-15~4F3-15) |
||||||
| Degree of protection | IP68(1m,1H) | Suitable for fuse size(mm) | 10*85 or 10/14*85 | ||||||
| Rated Impulse voltage | 12KV | Regulatory approval | TUV,CE | ||||||
