Application:
high voltage HRC current limiting fuses type XRNP for transformer
protection is mainly used in AC *0HZ,rated voltage 3.***0.5 kV.
rated current up to 6.3A circuit for protection transformers from
overload and shirt circuit. it conforms to IEC****1,BS and GB
****6.2
Desing Features
XRNP type H. V HRC current-limiting fuses is insert installation.
It is convenient for install and removal.
The fuse link made of high-resistance metal wire and low-resistance
metal wire. They are sealed in the fuse tube filled with chemically
treated high-purity quartzsand.
The fuse tube is made from heat tesistance, high duty ceramic or
epoxy glass. When fault circuit happens,
the fuse link melts causing arc, quartz sand dxtiguish the arc
immediately, signaling the melting or automatically cutting the
circuit.
| model | rated voltage (kv) |
rated current of fuselink (A) |
Rated breaking current(KA) |
Dimensions (mm) |
weight |
| XRNP1 | 3.6 | 0.5,1,2,3,*5,6.3 | *0 | See figure 1 **2 | 0.*9 |
| XRNP1 | 7.2 | 0.5,1,2,3.*5 | *0 | see figure 1 **2(**5) | 0.*9(0.*2) |
| XRNP1 | *2 | 0.5,1,2,3.*5 | *0 | See figure 1 **5 | 0.*2 |
| XRNP1 | *4 | 0.5,1,2,3.*5 | *0 | See figure 1 **5 | 0.*3 |
| XRNP1 | *0.5 | 0.5,1,2,3.*5 | *1.5 | See figure 1 **5 | 0.*5 |
| XRNP1 | *2 | 0.5,1,2,3.*5 | *0 | See figure 1 | 1.*2 |
