Gamma Interlocking Femoral Intramedullary Nail

Features:


• Made from titanium for superior strength, biocompatibility, and corrosion resistance.
• Features interlocking screws for enhanced stability, reducing the risk of rotational instability.
• Suitable for minimally invasive procedures, leading to faster recovery times.
• Available in multiple diameters and lengths to accommodate a range of patient anatomies.
• Ideal for fractures in the proximal femur and subtrochanteric regions.

• Intertrochanteric femur fractures
• Subtrochanteric femoral fractures
• Femoral shaft fractures requiring additional stabilization
• Hip fractures in elderly patients, especially those with osteoporotic bone
• Femoral fractures needing enhanced rotational stability

Contraindications:

• Active infections in the area of treatment
• Severe osteoporosis or insufficient bone quality to support the nail
• Allergies or sensitivities to titanium or its alloys
• Pediatric patients with open growth plates
• Severe deformities of the femur that are unsuitable for intramedullary fixation



Product Parameters:


Diameter (mm)	Length (mm)
9.5	170, 200, 240
10.0	170, 200, 240
11.0	170, 200, 240
12.0	170, 200, 240

Femur Gamma Cap Parameters


Size (mm)	Dimensions (mm)
Φ13 × 4	Φ13 × 8
Φ13 × 10	Φ13 × 12

Instrument Set:
The product is compatible with the instrument set for Gamma interlocking intramedullary nail and Femoral retrograde intramedullary nail I, 8501-000.
