Product
Introduction
LED
Curtain Display , also called LED Mesh Display, is high
transparency outdoor led display.It is 65% lighter than
conventional LED display and has less requirement for steel
structure than conventional LED Display. High transparency ensure
it reduce much impact of the natural lighting and provide better
viewing for buildings than conventional one.
Good heat
dissipation，Easy
installation，Easy maintenance
Use fan-free, noise-free heat dissipation mode; The back
cover fins and hollow lamp strips make the heat dissipate
naturally; Installation and maintenance are super simple;
Convenient for transportation; The lamp strips can be
disassembled and replaced separately; Both front and rear
maintenance; Can be easily installed even by
non-professionals.
High efficiency， Energy saving，
High weather resistance
Using high-efficiency PFC power supply can save energy by more
than 75% compared with conventional display screen; It can be
applied to harsh environments such as high humidity, high
salinity, strong ultraviolet rays and high low
temperature
| Model | P16-16 | P16-33 | P25-25 | P33-33 | P25-50 |
| Pixel composition | 1R1G1B | 1R1G1B | 1R1G1B | 2R2G2B | 2R2G2B |
| LED type | DIP346 | DIP346 | DIP346 | DIP346 | DIP346 |
| Pixel density(dots/m²) | 3600 | 1800 | 1600 | 900 | 800 |
| Brightness（cd/m²) | 8000 | 7000 | 7000 | 7000 | 8000 |
| Power Avg.(W/m²) | 200 | 185 | 185 | 185 | 155 |
| Power Max.(W/m²) | 560 | 530 | 530 | 530 | 400 |
| Transparency rate (%) | 45 | 70 | 65 | 68 | 68 |
| Minimum view distance(m) | 16 | 25 | 25 | 33 | 37.5 |
| Cabinet size (mm) | 500×1000 | 500×1000 | 500×1500 | 500×1000 | 500×1000 |
| Cabinet weight (kg/pc) | 8 | 5 | 6.5 | 6.8 | 7 |
| Fixing structure weight (kg/m²) | 5 | ||||
| Refresh rate (Hz) | 1920-3840 | ||||
| Working temperature (℃) | -20 ~ +60 | ||||
| Working humidity (RH) | 10～90 | ||||
| Ingress protection(front & back) | IP65 | ||||
| Ventilation and heat dissipation | Natural ventilation | ||||
| Cleaning method | High-pressure water jet | ||||
| Shell material | Aluminium alloy | ||||
| Control system | Integration | ||||
| Maintenance mode | Front | ||||
| Life time (hrs) | 100000 | ||||
