Push Pull Pickling
Line
For coils to be
pickling:
Cold-rolled carbon
structural steel, high-quality carbon
structural steel and low
alloy steel
coils.
Steel type:
Q195/235, ST12/13, SPCC, SPCD and
20#
Yield strength:
210~360N/mm 2
Tensile strength:
270~610N/mm 2
Specifications
Coil
thickness:1.8~4.0mm
Coil width:
550~1400mm
Inner diameter of
coils to be pickled:
ф610mm/760mm
Inner diameter of
coils after pickling:
ф610mm
Coil outer
diameter: max.ф
2000mm
Coil weight: max
26t
Annual work plan:
300 days×24
hours
Energy: water,
electricity and
vapor
Product form:
coils one after
another
Production
capacity:
300000Ton/year
Max. Process
speed: 120m/min
Process method:
Push-pull shallow trough turbulence
hydrochloric acid
pickling
APU layout
direction: From left to right when seating at
operation out
board
Max. process
speed: 120m/min
Threading speed:
10~60m/min
Point move speed:
10~30m/min
Transmission way:
AV driving system, speed regulated by
variation
frequency
Acid
concentration: Max 200 g/L HCL, 125g/L Fe 2+ ,5 g/L Fe
3+
Min. acid pickling
time: 26s
Acid trough length
in total: about
50m
Whole ACU length:
about 120m
