Winner802 Photon Correlation DLS Nano particle Size Analyzer

FOB Price

Get Latest Price

23999 ~ 25999 USD / Set

1 Set Minimum Order

Country:

China

Model No:

winner802

FOB Price:

23999 ~ 25999 USD / Set (Negotiable) Get Latest Price

Place of Origin:

China(mainland)

Price for Minimum Order:

23999 per Set

Minimum Order Quantity:

1 Set

Packaging Detail:

wooden box with foam inside

Delivery Time:

1-2 days, according to your quantity

Supplying Ability:

30 Set per Month

Payment Type:

T/T

Product Group :

nano particle size analyzer

Contact Now

Jinan Winner Particle Instrument Co. Ltd.

China

Free Member

Contact Person Mr. jason

Jinan, Shandong

Contact Now

Product Specification

measure range:1-10000nm:accuracy ï¼�1%
concentration testing range:0.1mg/ml-100mg/ml
light source:semiconductor laser
scattering angle:90Â°
G.W:12kg

Product Description

Winner**2 dynamic light scattering nanometer particle size analyzer which based on the dynamic light scattering principle, and also 1^st one which use digital correlator in China. And Its upgrade from Winner**1, which is 1^st set of Nanometer particle size analyzer. Based on Brownian motion principle, smaller particle, faster speed, bigger particle, more slowly. It adopt great performance of Japan HAMAMATSU photomultiplier and self-developed high speed digital correlator as core parts, Get diffusion coefficient by test scattering light change in some angle, and calculate particle diameter and distribution according to stokes-Einstein equation. the machine is with characters of fast calculation, high resolution ration, good accuracy and repeatability, therefore its widely used in company product lab research and university use.

Application:
Nano metallic oxide, Nano metallic powder, Nano ceramic material, protein, polymer latex, preparation of pharmaceutical, water/oil emulsion, paint, coating material, pigment, ink, toner, cosmetics and other fields of research, preparation and application of nano materials.

Model		Winner **2
Standard		GB/T *******5/ISO 1:6 GB/T ******2/ISO 2:*8
Measure range		******0nm
Concentration range		0.1mg/ml****0mg/ml
Accuracy error		<1%( D*0 of National standard sample)
Repeatability error		<1% ( D*0 of National standard sample)
Light source		Semiconductor laser λ= *2nm P=0mW
Detector		Imported HAMAMATSU photo-multiplier
Scattering angle		*0^o
Sample cuvette		*-4mL
Temperature control		***0 ℃（temperature controller within 0.1℃）
Test speed		<5 Min
Outer Dimension		L8cmW7cmH*7cm
G.W.		*2Kg
Operation system		Win XP/Win 7/Win 0 4 bits
Analysis		Average particle diameter, particle distribution, photon counting rate etc.
Digital Correlator	Model	CR**6
	Auto-correlation channels	**6
	Baseline channel	4
	Unit delay time	0ns0ms

Main Features:

1) Advanced test principle:
Dynamic light scattering principle and photon correlation spectrum technology, according to Brownian motion speed of particle to test particle size, different size of particles have different speed, when laser illuminate these particles, it will make scattering light happen different speed of fluctuations- downs.
Photo correlation spectrum method will analyze these particle size according to Photon fluctuations -downs in particular direction.

  2) High resolution:
Using PCR technology test nanometer-scale particle size, must be able to distinguish nanosecond signal fluctuations. The core components of the instrument is CR**6 digital correlator developed by our company, with 8ns high resolution speed.

3) High sensitivity and Noise-signal ratio
  Detector is composed of imported HAMAMATSU photomultiplier, so ensure good accuracy.

4) High speed data collection and calculation
  Self-developed patent product-CR**6 digital correlation, It could finish dynamic scattering light intensity collection and autocorrelative function real time calculation, Data processing speed is up to **2M, effectively reflect dynamic scattering light information of different sizes of particles.

5)High stable light path system
  Photon correlation spectrum detect system adopt optical-fibre technology, smaller size and high anti-interference and reliability.

6)High precision constant temperature control system
  Semiconductor temperature control technology, precision control within ±0.1℃，make samples be in a constant state throughout the testing process, prevent testing error because temperature change will change liquid viscosity and Brownian movement speed.

7) Output parameters: freely set D**-D**0, D[4,3],D[3,2], D[2,1],D[1,0] and specific surface area.
