Cat6A STP Toolless RJ45 Connectors

Product Description

CRXCONEC smart Cat.6A field termination RJ45 plug is available in STP version, special design for easy, fast and reliable installation with a screw-fit boot, IP20 anti-dust plug cover is provided as well. This new category 6a field termination rj45 plug provide outstanding network cabling solutions for data center and also applied the connection to WAP, IP Cameras and various IP devices. It is designed to terminate with Cat6a or Category 7 larger diameter ethernet cables and suitable with the cable outer diameter from 6.0 to 8.0mm. It provides the outstanding network cabling solution for the data center and meets for the PoE plus (IEEE 802.3at) application.



Features

• Black color Cat.6A Toolless Field Termination plug is designed to terminate with Cat6a or Cat7 larger diameter (23AWG to 26AWG).
• Fast and dependable installation.
• Long latch design is very easy to plug in and out for high density application.
• The screw-fit boot can be fitted with cable outer diameter from 6.0 to 8.5mm which can apply for 22AWG to 26AWG cable.
• A dust cover will be included as a part of this plug, it provides the protection under IP20 level.
•
•
  Cat.6A FTP toolless plug color black



  Cat.6A Field Tool free Plug product overview


  Applications

  Crxconec CAT.6a Shielded toolless RJ45 plug could apply with different outlet such as keystone Jack and patch panel, faceplate and surface mount box, RJ45 Cat6A STP plug is applicable with 23-26 AWG wire guage cable performed 500MHZ frequency, because of the highly specification, it can be used in the Data center or any indoor working areas.


  Cat.6A shielded ftp toolless plug



  Cat.6A Field Termination Plug MPTL

  Modular plug terminated link (MPTL) limits for DSX-5000 or DSX-8000, it has to use a Permanent link adaptor on the main fluke and one patch cord adaptor at the end of the fluke.




  RJ 45 Field Termination Plug Cat6a OEM Availability

  CRXCONEC can provide OEM option to build your own toolles plug, the OEM options included to make your own latch design, and also you can put your logo on it.


  Material

  1. Extractor: PC, UL 94V-2, Options Color
  2. Housing: Zinc die-Casting with nickel plated
  3. RJ45 Plug:
  3-1 Housing: PC, UL 94V-2, Black Color
  3-2 Contact Finish: 50 micro-inch gold plated on surface contact area
  4. Cover: Zinc die-casting with nickel plated
  5. Wire Management Bar: PC+glass fiber, white color, UL94-V2
  6. IDC:
  6-1 Housing: PC, white color, UL94-V2
  6-2 Terminal: Titanium copper with tin plated
  7. Grounding Contact: Zinc die-casting with nickel plated
  8. Boot:
  8-1 Housing: Zinc die-casting with nickel plated
  8-2 SR: PC, UL 94V-2, Black Color
  9. PCB, UL 94-V0

  Cat.6A FTP Toolless Plug Packaging

  CRXCONEC Cat.6A Toolless Plug gathers 50 pieces into 1 inner box, and 10 inner boxes gather into 1 carton.

  Purchase Information

  Price Term: FOB Taiwan or FOB Ningbo
  Payment Term: T/T, credit card, or pay pal
  Lead Time: 4 weeks after order confirmation
