Jiangyin Spark XH-BCT Series of Solid Core Current Transformer
design for better accuracy for 0.333V output .5 standard models for
your choice. Measure
current from 5Amp to 600 Amp.Solid core CTs are more accurately ,
small in size, and very cheap .If mA sendary output ,accuracy can
be 0.1%
Specifications:
1. Rated current from 5A to
600A
2. 0.333V AC or other mA ,mV output at rated
current
3. Accuracy ±0.5% or 0.1%
4.Insulation
Voltage:5400V, CATIII 600V or CATIV
250V
5.Accuracy at 10% to 130% of rated
current
6.Rated
Frequency:50HZ or 60HZ;
7.RoHS Compliant
8.Operating
Temperature:-40ºC to +55ºC
9.Flame
resistance:UL94-V0;
10.Tensile force value: 9.08
kg(89N) for 1 minutes;
| Model | I.D. | Rated Amps | Output |
Outside Diameter |
Height |
| XH-BCT-0300 |
0.39 in. 0.76 cm |
1A to 50 | mA or 0-5V output |
1.70 in. 4.32 cm |
0.75 in. 1.91 cm |
| XH-BCT-0500 |
0.50 in. 1.27 cm |
5A to 150A | mA or 0-5V output |
1.90 in. 4.83 cm |
0.75 in. 1.91 cm |
| XH-BCT-0750 |
0.75 in. 1.91 cm |
10A to 250A | mA or 0-5V output |
2.10 in. 5.33 cm |
0.75 in. 1.91 cm |
| XH-BCT-1000 |
1.00 in. 2.54 cm |
50A to 400A | mA or 0-5V output |
2.40 in. 6.10 cm |
0.80 in. 2.03 cm |
| XH-BCT-1250 |
1.25 in. 3.18 cm |
50A to 600A | Ma or 0-5V output |
2.70 in. 6.86 cm |
0.80 in. 2.03 cm |
